TJL-12 ice detection load cell has good weather resistance and sealing stable performance. The main supply of high voltage power transmission and transformation engineering, used for power transmission and transformation line ice-covered online monitoring system tension monitoring and measurement, and according to customer requirements to add analog transmitter or digital module.
| Technical Parameter | |
| Rated Load | 40~1100 kN |
| Comprehensive Precision | 0.2~0.5% FS |
| Sensitivity | 1.5 mV/V |
| Creep | ±0.2% FS/30min |
| Zero Output | ±1% FS |
| Temperature Effect On Zero | ±0.2% FS/10℃ |
| Temperature Effect On Output | ±0.2% FS/10℃ |
| Operating Temperature Range | -40~+70 ℃ |
| Input Resistance | 680±15 Ω |
| Output Resistance | 650± 5 Ω |
| Insulation Resistance | ＞5000 MΩ |
| Safe Load Limit | 120% FS |
| Bridge Voltage | Reference 10V DC |
| Material | Stainless Steel |
| Load Cell Mode Of Connection | Input+: Red |
| Input-: Black | |
| Output+: Green | |
| Output-: White | |
